LSJ Series IQF Spiral Freezer

Ideal for granulated and small-piece food, large-sized frozen food, such as the prepared meals, whole chicken, and whole fish

PRODUCT DETAILS

PRODUCT OVERVIEW

With the frozen food industry growing rapidly, the LSJ IQF spiral freezer(spiral IQF) is now a top choice. It’s ideal for companies needing compact, efficient machines. This equipment supports both top-blow and lateral-blow freezing. Freezing times can be adjusted from 20 to 90 minutes. It works perfectly for large and high temperature food.For example, prepared foods, small packages, and cross-cut meats. It’s also great for freezing ice cream and similar products.

In addition, it can handle seafood, fruits, and vegetables. These items may not suit traditional Spiral IQF processes. As its flexible design, it fits various production needs. So it helps companies streamline operations while ensuring quality. Whether freezing delicate produce or sturdy meats, it delivers reliable results every time.

PRODUCT FEATURES

  1. The IQF spiral freezer features a compact multi-layered spiral structure, resulting in1/3 to 1/2 less floor space compared to traditional freezers with similar capacity—perfect forfacilities prioritizing space efficiency.



  1. By combining years of hands-on experience withadvanced international technologies, the LSJ IQF spiral freezer delivers unmatched reliability. Thanks to its robust mechanical and electrical safety features, it ensures worry-free operation for demanding industrial environments.



  1. Equipped with customizable import/export directions, this freezer adapts effort lessly to diverse food production layouts. Whether paired with frying lines, packaging systems, or processing units, it streamlines workflows while boosting productivity.



  1. Designed for simplicity, the spiral IQF freezer requires minimal training to operate. Key high lights include an aluminum alloy evaporator with easy-clean fins (reducing bacterial build up) and a high-speed cleaning system that dries conveyor belts instantly (ensuring strict hygiene standards). Plus, its durable design cuts maintenance costs with fewer replaceable parts.



  1. Ideal for a variety of frozen foods, this versatile unit handles everything from noodles, spring rolls, and meat products to fruits, vegetables, fried snacks, and small packaged goods—making it a universal solution for food processors.



  1. Built with premium SUS304 stainless steel, the freezer ensures direct product placement on its conveyor belt. The belt’s smooth surface leaves negligible marks on items, whileside chains with anti-slip stoppers keep trays securely in place—eliminating product waste.



  1. To optimize performance, we’ve engineered symmetrical circular wind ducts around the spiral tower and evaporator. This innovative design not only accelerates heat exchange but also prevents cold loss at entry/exit points. Best of all, it maintains operator-friendly access forhassle-free maintenance.

SPECIFICATIONS

LSJ Single Drum Spiral IQF Freezer
Capacity
(KG/H)
Freezing Time
(Min)
Refrigeration Consumption(kw)Install Power
(Kw)
Overall Dimension
L×W×H (M)
LSJ-I-50050015-908516.27×5.8×3.1
LSJ-I-75075015-9012521.77.5×6×3.3
LSJ-I-1000100015-9016522.97.7×6×3.8
LSJ-I-1500150015-9022024.68.3×6.2×4.5
LSJ-I-2000200015-90300278.8×6.5×4.8
LSJ Double Drum Spiral IQF Freezer

Capacity
(KG/H)
Freezing Time
(Min)
Refrigeration Consumption(kw)Install Power
(Kw)
Overall Dimension
L×W×H (M)
LSJ-II-1000100015-901652012.5×4.6×3.1
LSJ-II-1500150015-902202413.1×5.0×3.6
LSJ-II-2000200015-903003216.1×5.1×3.9
LSJ-II-2500250015-903604016.1×5.3×4.3
LSJ-II-3000300015-904004617.6×6×4.8

Note:Feeding temperature +15℃,discharging temperature -18℃,refrigerant R717 or R22.



Related Turnkey Food Processing  Solutions:

Cooked Prawn Freezing Production Line

Seafood Freezing Production Line

Crayfish Processing Turnkey Solution



Request More Information

Please let us know the materials you need to process and your production requirements. We will offer you professional suggestions on solutions.
